Lutron AM-4204 Hot Wire Anemometer

Click To Zoom

Lutron AM-4204 Hot Wire Anemometer

Lutron AM-4204 Hot Wire Anemometer

(Based On 10 Reviews)

The AM-4204 Hot Wire Anemometer provides accurate and reliable measurements for air velocity and temperature, making it an essential tool for various environmental and HVAC applications

Request Callback

Order In Bulk

Generate Quote

100% ORIGINAL Products Details

100% ORIGINAL Products

SECURE Payments Details

SECURE Payments

₹ 11,700.00

(GST inclusive price) i
  • Base Value: ₹ 9915.3
  • GST: (18) % ₹ 1784.7
  • Total Value ₹ 11700

₹11,700.00

( - 0% OFF )

Need Help ?

Our Client Care Managers Are On Call 24/7 To Answer Your Question.

8920884830

Description

Key Features



  •  High Precision Measurement: Thermal anemometer suitable for very low air velocity measurements, ensuring accurate readings even at low speeds.
  •  Slim Probe Design: Ideal for use in grilles and diffusers, allowing for easy access to hard-to-reach areas.
  •  Combination Sensor: Combines a hot wire sensor with a standard thermistor to deliver rapid and precise measurements.
  •  Large Dual Function Display: Features a super large LCD with dual function display, allowing simultaneous reading of air velocity and temperature.
  •  Durable and Portable: Constructed with a heavy-duty, lightweight ABS-plastic housing case, providing durability and portability.

What's in The Box?

  • Instruction manua
  • Telescope Probe
  • Hard carrying case

Rating & Reviews

4.5
(Based On 10 Reviews)

Rating

0

0

0

0

0

Product Specifications

General Specification
CircuitCustom one-chip of micro- processor LSI circuit
Display* 13 mm(0.5") Super large LCD  display * Dual function meter's display
Measurement

m/s (meters per second) km/h (kilometers per hour) ft/min (feet/per minute) knots (nautical miles per hour) mile/h(miles per hour)Temp.- , .Data hold.



Sensor Structure

Air velocity : Tiny glass bead thermistor

Temperature : Precision thermistor.

MemoryMaximum and Minimum with recall.
Sampling Time Approx. 0.8 sec.
Power offAuto shut off saves battery life or manual off by push button.
Data OutputRS 232 PC serial interface.
Operating Temperature0 to 50 (32 to 122 ).
Operating HumidityLess than 80% RH.
Power Supply1.5 V AAA (UM-4) battery x 6 PCs (Alkaline or heavy duty type).
Power CurrentApprox. DC 30 mA.
Weight355 g/0.78 LB.
Dimension

Main instrument: 180 x 72 x 32 mm ( 7.1 x 2.8 x1.3 inch ).

Telescope Probe : Round, 12 mm Dia x 280 mm ( min. length ).x 940 mm ( max. length )



Electrical Specification
MeasurementRangeResolutionAccuracy
m/s0.2 - 20.0 m/s0.1 m/s

± ( 5 % + 1 d ) reading

or

± ( 1 % + 1 d ) full scale

* Depend on which is larger

km/h0.7 - 72.0 km/h0.1 km/h
ft/min40 - 3940 ft/min1 ft/min
mile/h0.5 - 44.7 mile/h0.1 mile/h
knots0.4 - 38.8 knots0.1 knots
