Fluke 289 True-RMS Data Logging Multimeter

Click To Zoom

Fluke 289 True-RMS Data Logging Multimeter

Fluke 289 True-RMS Data Logging Multimeter

(Based On 10 Reviews)

The Fluke 289 is the next generation high performance industrial logging multimeter. This Fluke Connect-compatible DMM is designed to solve complex problems in electronics, plant automation, power distribution, and electro-mechanical equipment. Let the 289 be your watchdog for systems or processes while you are off doing other jobs. It provides the ability to log data and graphically review up 10,000 recorded events and logged readings with on-board TrendCapture. Zoom on trend provides a 14x zoom to view and analyze data—without needing a PC.

Because the 289 is Fluke Connect-compatible you can set it up with the ir3000 FC wireless connector (sold separately) to communicate with your iOS and Android smart devices through the Fluke Connect mobile app and monitor readings from a remote location. Or you can share readings with your team in an instant anytime, from anywhere with ShareLive video call. It can help you solve problems faster and minimize downtime.

Request Callback

Order In Bulk

Generate Quote

100% ORIGINAL Products Details

100% ORIGINAL Products

SECURE Payments Details

SECURE Payments

₹ 89,600.00

(GST inclusive price) i
  • Base Value: ₹ 75932.2
  • GST: (18) % ₹ 13667.8
  • Total Value ₹ 89600

₹1,21,831.00

( - 26% OFF )

Need Help ?

Our Client Care Managers Are On Call 24/7 To Answer Your Question.

8920884830

Description

Key Features

  • Share results with your team using ShareLive video call (requires ir3000 FC wireless connector [sold separately] and no-cost Fluke Connect mobile app).
  • TrendCapture graphically displays logged data session to quickly determine whether anomalies may have occurred.
  • Zoom on trend provides unprecedented ability to view and analyze TrendCapture data; zoom in up to 14 times.
  • Selectable AC filter (smoothing mode) helps display a steadier reading when the input signal is changing rapidly or noisy.
  • Low Pass filter for accurate voltage and frequency measurements at the same time on adjustable speed motor drives and other electrically noisy equipment.
  • LoZ Volts. Low impedance voltage function for eliminating ghost voltages. Also recommended when testing for absence or presence of live power.
  • Adjustable recording and auto hold thresholds, specify a percentage change in the readings that begins a new event.
  • Large 50,000 count, 1/4 VGA dot matrix display with white backlight.
  • Measure up to 10 A (20 A for 30 seconds).
  • 100 mF capacitance range





Other Useful Features:

  • Provides up to a 14x zoom to view and analyze TrendCapture data in depth
  • Includes a selectable AC filter (smoothing mode) to help display a steadier reading when the input signal is changing rapidly or noisy.
  • Offers adjustable recording and auto hold thresholds to specify a percentage change in the readings that begins a new event
  • Features a large 50,000 count, 1/4 VGA dot matrix display with white backlight
  • Stores up to 15,000 recorded events so you can save multiple logging sessions before PC download is necessary
  • Provides two-terminal 50 ohm range with 1 milliohm resolution, 10 mA source current, for measuring and comparing differences in motor winding resistance or contact resistance
  • Includes low pass filter for accurate voltage and frequency measurements at the same time on adjustable speed motor drives and other electrically noisy equipment.
  • Provides LoZ Volts, a low impedance voltage function for eliminating ghost voltages Recommended when testing for absence or presence of live power
  • Features on-board help screens for measurement functions
  • Includes a real-time clock to automatically time stamp saved readings
  • Offers relative mode to remove test lead resistance from low ohms or capacitance measurements
  • Provides True-RMS AC voltage and current for accurate measurements on non-linear signals
  • Measures up to 10 A (20 A for 30 seconds)
  • Provides up to 100 mF capacitance range
  • Records transients as fast as 250 μs with peak capture
  • Includes premium test leads, alligator clips, and amp jack plugs
  • Offers optional magnetic hanger for easy setup and viewing while freeing your hands for other tasks
  • Works with optional FlukeView forms to enable you to document, store and analyze individual readings or a series of measurements, then convert them into professional-looking documents.
  • Includes a limited lifetime warranty.





What's in the box?

  • 289 True-RMS Industrial Logging Multimeter
  • TL71 Test Leads
  • AC175 Alligator Clips
  • Batteries – 6 AA Installed

Rating & Reviews

4.5
(Based On 10 Reviews)

Rating

0

0

0

0

0

Product Specifications

Specifications
Function
DC voltsRange / resolution50.000 mV, 500.00 mV, 5.0000 V, 50.000 V, 500.00 V, 1000.0 V
Basic accuracy0.025%
AC voltsRange / resolution50.000 mV, 500.00 mV, 5.0000 V, 50.000 V, 500.00 V, 1000.0 V
Basic accuracy0.4% (True-RMS)
DC currentRange / resolution500.00 μA, 5000.0 μA, 50.000 mA, 400.00 mA, 5.0000 A, 10.000 A
Basic accuracy0.05%
AC currentRange / resolution500.00 μA, 5000.0 μA, 50.000 mA, 400.00 mA, 5.0000 A, 10.000 A
Basic accuracy0.6% (True-RMS)
Temperature (excluding probe)Range / resolution-200.0°C to 1350.0°C (-328.0°F to 2462.0°F)
Basic accuracy1.0%
ResistanceRange / resolution50.000 Ω, 500.00 Ω, 5.0000 kΩ, 50.000 kΩ, 500.00 kΩ, 5.0000 MΩ, 50.00 MΩ, 500.0 MΩ
Basic accuracy0.05%
CapacitanceRange / resolution1.000 nF,10.00 nF 100.0 nF, 1.000 μF, 10.00 μF, 100.0 μF, 1000 μF, 10.00 mF, 100 mF
Basic accuracy1.0%
FrequencyRange / resolution99.999 Hz, 999.99 Hz, 9.9999 kHz, 99.999 kHz, 999.99 kHz
Basic accuracy0.005%
ConnectivityOptional infrared connector via Fluke ir3000 FC
General Specifications
Maximum voltage between any terminal and earth ground1000 V
Battery type6 AA alkaline batteries, IECLR6
Battery life100 hours minimum, 200 hours in logging mode
TemperatureOperating-20°C to 55°C
Storage-40°C to 60°C
Relative humidity0 to 90% (0 to 37°C), 0 to 65% (37°C to 45°C), 0 to 45% (45°C to 55°C)
Electromagnetic compatibilityEMC EN61326–1
VibrationRandom vibration per MIL-PRF-28800F Class 2
Shock1 meter drop per IEC/EN 61010–1 3rd Edition
Size (H x W x L)22.2 x 10.2 x 6 cm (8.75 x 4.03 x 2.38 in)
Weight870.9 g (28 oz)
Multiple on screen displaysYes
True-RMS AC bandwidth100 kHz
dBV/dBmYes
DC mV resolution1 μV
Megohm rangeUp to 500 MΩ
Conductance50.00 nS
Continuity beeperYes
Battery/fuse accessYes/Yes
Elapse time clockYes
Time of day clockYes
Min-max-avgYes
Duty cycleYes
Pulse widthYes
Isolated optical interfaceYes
Auto/touch holdYes
Reading memoryYes
Log to PCYes
Interval/event loggingYes
Logging memoryUp to 15,000 readings
Wireless connectivity (optional)Yes
