Lutron MO-2001 MILLIOHM METER

Click To Zoom

Lutron MO-2001 MILLIOHM METER

Lutron MO-2001 MILLIOHM METER

(Based On 10 Reviews)

The MO-2001 Milliohm Meter offers accurate and reliable low resistance measurements, making it an essential tool for various applications in industrial, mechanical, and electrical environments.

Request Callback

Order In Bulk

Generate Quote

100% ORIGINAL Products
100% ORIGINAL Products Details

100% ORIGINAL Products

SECURE Payments
SECURE Payments Details

SECURE Payments

₹ 14,918.00

(GST inclusive price) i
  • Base Value: ₹ 12642.4
  • GST: (18) % ₹ 2275.6
  • Total Value ₹ 14918

₹14,918.00

( - 0% OFF )

Need Help ?

Our Client Care Managers Are On Call 24/7 To Answer Your Question.

Description

Key features



  •  4-Terminal Measurement: Provides accurate measurement of very low resistance using 4-terminal devices.
  •  Large LCD Display: Features an 18 mm (0.7") large size LCD display for easy readability.
  •  Wide Measuring Range: Supports a wide measuring range from 0.1 mΩ to 2000 Ω across 5 ranges.
  •  Durable and Portable: Comes with a durable plastic housing case and a front protective cover for portability and protection.
  •  Built-In Over Input Indication: Alerts users of over input situations to prevent damage to the meter.




What's in the box?

  • Power Cable (1 PC)
  •  4 Wires with 2 Clips (1 Pair)
  •  Instruction Manual (1 PC)

Rating & Reviews

4.5
(Based On 10 Reviews)

Rating

0

0

0

0

0
Review Image

Product Specifications

Technical Specifications:






 Measurement Ranges:

   200 mΩ:

  •      Resolution: 0.1 mΩ
  •      Test Current: 100 mA
  •      Accuracy: ± (0.75% + 4 d)
  •      Open Circuit Voltage: Approx. 3.8 V DC

   2000 mΩ:

  •      Resolution: 1 mΩ
  •      Test Current: 10 mA
  •      Accuracy: ± (0.75% + 2 d)
  •      Open Circuit Voltage: Approx. 3.4 V DC

   20 Ω:

  •      Resolution: 10 mΩ
  •      Test Current: 10 mA
  •      Accuracy: ± (0.75% + 2 d)
  •      Open Circuit Voltage: Approx. 3.4 V DC

   200 Ω:

  •      Resolution: 0.1 Ω
  •      Test Current: 1 mA
  •      Accuracy: ± (0.75% + 2 d)
  •      Open Circuit Voltage: Approx. 3.2 V DC

   2000 Ω:

  •      Resolution: 1 Ω
  •      Test Current: 1 mA
  •      Accuracy: ± (0.75% + 2 d)
  •      Open Circuit Voltage: Approx. 3.2 V DC




  General Specifications:

   Display

  • 18 mm (0.7") LCD, max. indication 1999

   Zero Adjustment

  • External adjustment for zero value of the display

   Input Terminal:

  • 4 terminal input for accurate low ohms measurement

   Over Input Indication:

  • Displays "1" for over input

   Sampling Time:

  • Approx. 0.4 seconds

   Operating Temperature:

  • 0℃ to 50℃ (32℉ to 122℉)

   Operating Humidity:

  • Less than 80% RH

   Power Supply:

  • AC 110V ±10%, 50/60 Hz or AC 220V/240V ±10%, 50/60 Hz

   Power Consumption:

  • Approx. 2.5 VA

   Dimensions:

  • 170 x 120 x 90 mm (6.7 x 4.7 x 3.5 inches)

   Weight:

  • Approx. 690 g (1.52 lb)
