HIOKI FT3701-20 IR Thermometer
Click To Zoom
HIOKI FT3701-20 IR Thermometer
HIOKI FT3701-20 IR Thermometer
The HIOKI FT3701-20 is a non-contact infrared thermometer with a long focus and wide measurement area, ideal for measuring temperatures at a distance. It features a two-point laser marker for precise targeting and a user-friendly design.
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL Products
SECURE Payments
₹ 17,778.00
(GST inclusive price) i₹17,778.00
( - 0% OFF )
Description
What's in the Box
|
Rating & Reviews
Rating
Product Specifications
| SPECIFICATIONS | |
| Measurement temperature range | -60.0 to 760.0 ˚C (-76 to 1400 ˚F) Guaranteed accuracy range is -35 to 500°C. (-31.0 to 932.0 ˚F) |
| Accuracy | 0.0 to 100.0 ˚C (-32.0 to 212.0 ˚F) : ±2 ˚C 100.1 to 500.0 ˚C (212.1 to 932.0 ˚F) : ±2%rdg. -35.0 to -0.1 ˚C (-31.0 to 31.9 ˚F) : ±10%rdg.±2 ˚C -60.0 to -35.1 ˚C (-76.0 to -31.1 ˚F) : Accuracy not specified 500.1 to 550.0 ˚C (932.0 to 1022 ˚F) (FT3700-20) 500.1 to 760.0 ˚C (932.0 to 1400 ˚F) (FT3701-20) : Accuracy not specified |
| Accuracy guarantee for temperature and humidity | 23 ˚C ±3 ˚C (73 ˚F ±5 ˚F) 80% RH or less (non-condensating) |
| Temperature coefficient | Measurement accurary × 0.1/ ˚C |
| Diameter of field of measurement | 100 mm at 3000 mm (Distance : Spot = 30 : 1) |
| Response time | 1 second (90%) |
| Detection element | Thermopile |
| Sighting | Two-point laser marker max 1mW (class 2), Red |
| Measurement wavelength | 8 to 14 µm [Thermal emissivity compensation]0.10 to 1.00 by steps of 0.01 |
| Functions | MAX | MIN | DIF (MAX-MIN) | AVG measurement, Alarm function, Backlight function |
| Operating temperature and humidity | 0 to 50˚C (32˚F to 122˚F), 80%RH or less (non-condensating) |
| Storage temperature and humidity | 10 to 50˚C (14˚F to 122˚F), 80%RH or less (non-condensating) 50 to 60˚C (122˚F to 140˚F), 70%RH or less (non-condensating) |
| Applicable standards | EMC : EN61326 Laser : IEC60825-1 CLASS 2 LASER |
| Dimensions | Approx.48 W × 172 H × 119 D mm (1.89" W × 6.77" H × 4.69" D) (excluding projections) |
| Mass | Approx. 256 g (9.0 oz.) (including LR03 alkaline battery × 2) |
| Power supply | LR03 alkaline battery × 2, 150mVA [Continuous operating time: Approx. 140 hours] (When laser marker and backlight are OFF) |
