Metravi PRO 468AC TRMS AC Leakage Current Clamp Meter

Click To Zoom

Metravi PRO 468AC TRMS AC Leakage Current Clamp Meter

Metravi PRO 468AC TRMS AC Leakage Current Clamp Meter

(Based On 10 Reviews)

TRMS AC Leakage Current Clamp Meter 6000 Counts, Auto-Backlit LCD Display, Auto Power Off, as per IEC 61557-13: Class 2, 40mm Jaw Dia, IEC / EN 61010-1, IEC / EN 61010-2-032, CAT. III 600V, Pollution Degree 2, EN 61326-1 EN 61326-2-2, bandwidth up to 1kHz, 1% accuracy, 0 – 6mA / 60mA / 600mA / 6A / 60A, With resolution of 1uA, Bluetooth connection to connect it to freely available APP for recording data.



Request Callback

Order In Bulk

Generate Quote

100% ORIGINAL Products Details

100% ORIGINAL Products

SECURE Payments Details

SECURE Payments

₹ 45,249.00

(GST inclusive price) i
  • Base Value: ₹ 38346.6
  • GST: (18) % ₹ 6902.4
  • Total Value ₹ 45249

₹45,249.00

( - 0% OFF )

Need Help ?

Our Client Care Managers Are On Call 24/7 To Answer Your Question.

8920884830

Description

Key Features

  • 6000 counts digital display
  • Large white LED backlight display
  • AC True RMS reading
  • High frequency rejection (selectable, cut-off frequency: 50Hz~60Hz, 1kHz)
  • AC 60 Amps capability
  • AC 1µA resolution
  • Bluetooth connection with smartphone app
  • Smart hold
  • Min/Max hold
  • Torch light
  • Auto power off (can be disabled)
  • Battery capacity indication in segments
  • Up to 40mm dia. conductor size
  • 4 feet drop proof
  • Deluxe carrying case
  • Hand guard & streamlined design
  • Convenient battery door
  • CAT III 600V safety standard
  • Designed to meet: IEC 61557-13: Class 2 ≤ 30A/



What's in the box?

  • TRMS AC Leakage Current Clamp Meter

Rating & Reviews

4.5
(Based On 10 Reviews)

Rating

0

0

0

0

0

Product Specifications

Electrical Specification
 AC Function
 ACA specifications are ac coupled, true RMS.
• For non-sinusoidal waveforms, Additional Accuracy by Crest Factor (C.F.)Add 1.0% for C.F. 1.0 to 2.0
Add 2.5% for C.F. 2.0 to 2.5
Add 4.0% for C.F. 2.5 to 3.0
• Max. Crest Factor of Input Signal3.0 @ 3000 counts
2.0 @ 4500 counts
1.5 @ 6000 counts
Frequency Response is specified for sine waveform



AC Current
RangeAccuracy
30 to 50 Hz50 to 60 Hz 60 to 1k Hz
6mA*1 ± (2.0%+5D)*2± (1.0%+5D) ± (2.0%+5D)*3
60mA±( 2.0%+5D)*2± (1.0%+5D)± (2.0%+5D)*3
600mA± (2.0%+5D)*2± (1.0%+5D) ± (2.0%+5D)*3
6A± (2.0%+5D)± (1.0%+5D) ± (2.0%+5D)
60A± (2.0%+5D)± (1.0%+5D)± (2.0%+5D)
