Metravi CTG-01 Coating Thickness Gauge
Click To Zoom
Metravi CTG-01 Coating Thickness Gauge
Metravi CTG-01 Coating Thickness Gauge
The Metravi CTG-01 Coating Thickness Gauge works both on the magnetic induction principle and on the eddy current principle, depending on the type of probe used. You can select the type of probe via MENU system, or it will work automatically. The gauges confirm to the following industrial standards: GB/T 4956 -1985, GB/T 4957 – 1985, JB/T 8393 – 1996, JJG 889-95, JJG 818-93.
Request Callback
Order In Bulk
Generate Quote
₹ 15,923.00
(GST inclusive price) i₹15,923.00
( - 0% OFF )
Description
What's in the box?
|
Rating & Reviews
Rating
| General Specification | ||
| Sen | FERROUS | NON-FERROUS |
| Working principle | Magnetic Induction | Eddy Current |
| Measuring range | 0~1250um 0-49.21mils | 0-1250um 0~49.21mils |
| Guaranteed Tolerance (of readings) | 0-850 um (+/-3%+1um) 850um-1250 um (+/-5%) 0-33.46 mils (+/ (- 3)% +0.039mils) 33.46um-49.21mils (+/-5%) | 0-850 um(+/ (- 3)% + 1.5um ) 850um sim 1250um (+/-5\%) 0-33.46mils (+/-3%+0.059mils) 33.46um-49.21mils (+/-5%) |
| Precision | 0~50um (0.1um) 50um-850um (1um) 850um sim 1250um(0.01mm) 0-1.968mils (0.001mils) 1.968mils-33.46mils(0.01mils) 33.46mils-49.21mils(0.1mils | Oum-50um(0.1um) 50um - 850um(1um) 850um sim 1250um(0.01mm) 0-1.968mils (0.001mils) 1.968mils-33.46mils(0.01mils) 33.46mils-49.21mils(0.1mils |
| Minimum curvature radius | 1.5mm | 3mm |
| Diameter of Minimum area | 7mm | 5mm |
| Basic critical thickness | 0.5mm | 0.3mm |
| Working temperature | 0^ C sim40^ C(32^ F sim 104 deg * F ) | |
| Working relative humidity | 20% sim90\% | |
| Size (H X D X W) | 110 * 50 * 23 | |
| Weight | 100g | |
