Metravi PRO TIM-900 Professional Multimeter with Thermal Imager
Click To Zoom
Metravi PRO TIM-900 Professional Multimeter with Thermal Imager
Metravi PRO TIM-900 Professional Multimeter with Thermal Imager
The Metravi PRO TIM-900 is a professional T-RMS Industrial Digital Multimeter with a built-in Thermal Imager, having TFT Colour LCD, providing A/D Conversion with a high sampling rate and high accuracy; these features make it easy to find and solve the problems of the production equipment.
Request Callback
Order In Bulk
Generate Quote
₹ 72,293.00
(GST inclusive price) i₹72,293.00
( - 0% OFF )
Description
What's in the box?
|
Rating & Reviews
Rating
Product Specifications
| Technical Specifications | |
| Field of view (FOV) / Minimum focus distance | 21° x 21°/ 0.5m |
| Spatial Resolution (IFOV) | 4.53mrad |
| IR Resolution | 80 x 80 pixels |
| Thermal Sensitivity / NETD | < 0.1°C @ +30°C (+86°F) / 100 mK |
| Image Frequency | 50Hz |
| Focus Mode | Focus free |
| Focal Length | 7.5mm |
| Focal Plane Array (FPA) / Spectral Range | Uncooled microbolometer / 8-14 mm |
| Object Temperature Range | -20°C to +260°C (-4°F to + 500°F) |
| Accuracy | ±3°C (±5.4°F) or ±3% of reading (Environment temperature 10°C-35°C, object temperature >0°C. ) |
| DC Voltage | ||||
| Range | Resolution | Accuracy | Input impedance | Protection against overcharge |
| 400.0mV | 0.1mV | ± (0.8% reading + 8 digits) | >10MW | 600V DC/AC RMS |
| 4.000V | 0.001V | ± (0.5% reading + 5 digits) | ||
| 40.00V | 0.01V | |||
| 400.0V | 0.1V | ± (0.8% reading + 5 digits) | ||
| 600V | 1V | |||
| AC TRMS Voltage | ||||
| Range | Resolution | Accuracy (*) | Protection against overcharge | |
| 4.000V | 0.001V | (50Hz ~ 60Hz) | (61Hz ~1kHz) | 600V DC/AC RMS |
| 40.00V | 0.01V | ± (1.0% reading +5 digits) | ± (2.5% reading +5 digits) | |
| 400.0V | 0.1V | |||
| 600V | 1V | |||
| AC+ DC TRMS Voltage | ||||
| Range | Resolution | Accuracy (50Hz ~ 1kHz) | AC+ DC TRMS Voltage | Protection against overcharge |
| 4.000V | 0.001V | ± (2.5% reading +20 digits) | >10MΩ | 600V DC/AC RMS |
| 40.00V | 0.01V | |||
| 400.0V | 0.1V | |||
| 600V | 1V | |||
| DC Current | ||
| Range | Resolution | Accuracy |
| 200.0uA | 0.1µA | ± (1.5% reading + 5 digits) |
| 4000mA | 1mA | ± (2.0% reading + 8 digits) |
| 10.00A | 0.01A | ± (2.0% reading + 8 digits) |
| AC TRMS Current | ||
| Range | Resolution | Accuracy (*) (50Hz ~ 1kHz) |
| 200.0uA | 0.1µA | ± (2.0% reading + 5 digits) |
| 4000mA | 1mA | ± (2.5% reading + 5 digits) |
| 10.00A | 0.01A | ± (2.5% reading + 5 digits) |
| Resistance and Continuity Test | ||||
| Range | Resolution | Accuracy | Buzzer | Protection against overcharge |
| 400.0Ω | 0.1Ω | ± (1.0% reading + 10 dgt) | >50Ω | 600V DC/AC RMS |
| 4.000kΩ | 0.001kΩ | ± (1.0% reading + 5 dgt) | ||
| 40.00kΩ | 0.01 kΩ | |||
| 400.0kΩ | 0.1kΩ | |||
| 4.000MΩ | 0.001MΩ | |||
| 40.00MΩ | 0.01Mz | ± (2.5% reading + 10 dgt) | ||
| Frequency (Electrical Circuits) | |||
| Range | Resolution | Accuracy | Protection against overcharge |
| 40.00Hz ~ 10kHz | 0.01Hz ~ 0.001kHz | ± (0.5% reading) | 600V DC/AC RMS |
| Frequency (Electronic Circuits) | |||
| Range | Resolution | Accuracy | Protection against overcharge |
| 40.00Hz | 0.01Hz | ±(0.20% rdg +5 digits) | 600V DC/AC RMS |
| 400.0Hz | 0.1Hz | ||
| 4.000kHz | 0.001kHz | ||
| 40.00kHz | 0.001kHz | ||
| 400.0kHz | 0.1kHz | ||
| 4.000MHz | 0.001MHz | ||
| 10.00MHz | 0.01MHz | ||
| AC + DC TRMS Current | ||
| Range | Resolution | Accuracy (50Hz ~ 1kHz) |
| 200.0uA | 0.1µA | ± (3.0%reading + 20dgt) |
| 4000mA | 1mA | ± (3.0%reading + 20dgt) |
| 10.00A | 0.01A | ± (3.0%reading + 20dgt) |
