LUTRON YK-80AM Anemometr
Click To Zoom
LUTRON YK-80AM Anemometr
LUTRON YK-80AM Anemometr
The YK-80AM Metal Vane Anemometer provides accurate and reliable measurements of air velocity and temperature, making it an essential tool for various industrial, environmental, and HVAC applications.
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL Products
SECURE Payments
₹ 13,025.00
(GST inclusive price) i₹14,110.00
( - 8% OFF )
Description
What's in The Box ?
|
Rating & Reviews
Rating
| GENERAL SPECIFICATIONS | |
| Circuit | Custom one-chip of micro- processor LSI circuit. |
| Display | 51 mm x 32 mm supper large LCD display. Dual function meter's display. |
| Measurement | m/s (meters per second), km/h (kilometers per hour), ft/min (feet/per minute), knots (nautical miles per hour), mile/h(miles per hour), Temp.- ℃, °F., Data hold. |
| Sensor Structure | Air velocity: Metal diecasting structure. Conventional twisted van arm and low friction ball bearing design. Temperature : Thermistor. |
| Memory Recall | Records Maximum and Minimum readings with Recall |
| Power Off | Auto shut off saves battery life or manual off by push button |
| Sampling Time | Approx. 0.8 sec. |
| Data Output | RS 232 PC serial interface |
| Over load Indication | Indicated by"----". |
| Operating Temperatur | Meter: 0°C to 50°C (32 °F to 122 °F). Vane Probe: 0°C to 60°C (32 °F to 140 °F). |
| Operating Humidity | Less than 80% RH. |
| Power Supply | 006P DC 9V battery (heavy duty type). |
| Power Current | Approx. DC 8.3 mA. |
| Weight | 220 g/0.48 LB. |
| Dimension | 200 x 68 x 30 mm (7.9x2.7x1.2 inch). Sensor head: Round, 72 mm Dia |
| Electrical Specification | |||
| Measurement | Range | Resolution | Accuracy |
| m/s | 0.4 - 35.0 m/s | 0.01 m/s | ± ( 2% + 0.2 m/s ) |
| km/h | 1.4 - 126.0 km/h | 0.1 km/h | ± ( 2% + 0.8 km/h ) |
| mile/h | 0.9 - 78.3 mph | 0.1 mile/h | ± ( 2% + 0.4 mile/h ) |
| knots | 0.8 - 68.0 knots | 0.1 knots | ± ( 2% + 0.4 knots ) |
| ft/min | 79 - 6890 ft/min | 1 ft/min | ± ( 2% + 40 ft/min ) |
| Temperature(℃ ) | 0 to 60 ℃ ℃ | 0.1 ℃ | ± 0.8 ℃ |
| Temperature(℉ ) | 32 to 140 ℉ ℉ | 0.1 ℉ | ± 1.5 ℉ |
